Leasing SUNSKY Fuel Tanker for sale
Julkaistu: 10kk. 24p.
Julkaistu: 10kk. 24p.
China, office add: NO.178, XINFENG ROAD, HULI DISTRICT , XIAMEN CITY, CHINAFeature: Carry Fuel, Oil, Diesel etc.
Dimension(L*W*H): 12500*2500*3750mm(45,000L)
Model SS9400GRY
Material: Aluminum
Compartment: 6 （9500ltrs-5500ltrs-7500ltrs-7500ltrs-7500ltrs-7500ltrs）
Capacity(kgs): 45,000L
Tare weight(kgs): 9,000kgs
Kingpin Bolt-in 2”
Landing gear Two-speed manual operation 19”
Tire size 12R22.5(13pcs)
Rim size 9.00*22.5(13pcs)
Axle 13 Tons, 3 Axle
Leafs spring Air suspension with front axle lifting.
Brake system Dual line with Re-6 emergency relay valve, T30/30 air
chamber, 46L air tank
Manhole: Aluminum alloy ø500mm(20”) manhole with aluminum alloy cover; with breather valve;
Discharge Valve Aluminum alloy discharge valve with cover
Foot Valve Pneumatic control DN80 aluminum alloy foot valves
Pneumatic Control system 1set Pneumatic Control combined switch，1unit emergency switch
Discharge Hose 2 units 3”×6M factory PVC hose with quick coupling on both ends
Vapor Recovery& Overfill system Without
Fire Extinguisher Carrier 2 units at the left of rear of tanker, include 2 units 8kg dry powder type fire extinguisher inside
Electric system: One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable
Prime& Topcoat painting S.A.2.5 standard sandblasting ;Zinc-rich & Polyurethane painting
